Component Development Guide

Complete guide to developing and maintaining UI components for the Cascadia Marquee website.

Component Architecture

The website uses a layered component architecture:

UI Components - Base components from shadcn/ui
Layout Components - Page structure and navigation
Feature Components - Business logic and functionality
Content Components - MDX and content-specific components

Component Structure

src/components/
├── ui/                    # shadcn/ui base components
├── layout/                # Layout and navigation
│   ├── layouts/           # Page layouts
│   ├── partials/          # Header, footer, sidebar
│   └── sections/          # Page sections
├── contact/               # Contact form components
├── charts/                # Data visualization
├── icons/                 # Custom icons
├── text/                  # Typography components
└── container/             # Layout containers

Adding New UI Components

Using shadcn/ui (Recommended)

Install a component:

pnpm dlx shadcn@latest add button
pnpm dlx shadcn@latest add card
pnpm dlx shadcn@latest add dialog

Components are automatically added to:
- src/components/ui/[component-name].tsx
- src/components/ui/index.ts (export)

Use the component:

import { Button } from "@/components/ui/button";
import { Card } from "@/components/ui/card";

Available shadcn/ui Components

Button - Interactive buttons with variants
Card - Content containers
Dialog - Modal dialogs
Input - Form inputs
Label - Form labels
Select - Dropdown selects
Textarea - Multi-line text inputs
Badge - Status indicators
Alert - Alert messages
Accordion - Collapsible content
Tabs - Tabbed interfaces
Tooltip - Hover tooltips
Dropdown Menu - Context menus
Command - Command palette
Form - Form handling
Checkbox - Checkbox inputs
Switch - Toggle switches
Slider - Range sliders
Progress - Progress bars
Separator - Visual separators
Aspect Ratio - Responsive containers
Hover Card - Hover content
Collapsible - Collapsible sections
Resizable - Resizable panels
Drawer - Mobile-friendly drawers
Sonner - Toast notifications

Creating Custom Components

Component Template

import { cn } from "@/lib/utils";
import { forwardRef } from "react";

interface ComponentProps {
  className?: string;
  children?: React.ReactNode;
  // Add other props as needed
}

const Component = forwardRef<HTMLDivElement, ComponentProps>(
  ({ className, children, ...props }, ref) => {
    return (
      <div ref={ref} className={cn("base-styles", className)} {...props}>
        {children}
      </div>
    );
  }
);

Component.displayName = "Component";

export { Component };

Component Best Practices

Use forwardRef for proper ref forwarding
Include className prop for customization
Use cn() utility for conditional classes
Export with displayName for debugging
Follow TypeScript interfaces for type safety

Example: Custom Card Component

import { cn } from "@/lib/utils";
import { forwardRef } from "react";

interface CustomCardProps {
  className?: string;
  children?: React.ReactNode;
  variant?: "default" | "outlined" | "elevated";
  size?: "sm" | "md" | "lg";
}

const CustomCard = forwardRef<HTMLDivElement, CustomCardProps>(
  ({ className, children, variant = "default", size = "md", ...props }, ref) => {
    return (
      <div
        ref={ref}
        className={cn(
          "bg-card text-card-foreground rounded-lg border",
          {
            "border-border": variant === "default",
            "border-primary border-2": variant === "outlined",
            "shadow-lg": variant === "elevated",
            "p-4": size === "sm",
            "p-6": size === "md",
            "p-8": size === "lg",
          },
          className
        )}
        {...props}
      >
        {children}
      </div>
    );
  }
);

CustomCard.displayName = "CustomCard";

export { CustomCard };

Component Registry System

The website uses an automated component registry for dynamic component loading:

Registry Structure

// src/__registry__/index.tsx
export const Index = {
  charts: {
    "bar-chart": {
      name: "bar-chart",
      component: React.lazy(() => import("@/components/charts/bar-chart")),
    },
    "shopify-loading-speed-to-conversion-chart": {
      name: "shopify-loading-speed-to-conversion-chart",
      component: React.lazy(
        () => import("@/components/charts/shopify-loading-speed-to-conversion-chart")
      ),
    },
  },
  examples: {
    // Example components
  },
};

Adding Components to Registry

Place component in appropriate directory:
- Charts: src/components/charts/
- Examples: src/components/examples/
Run registry build:
pnpm run build:registry
Component is automatically registered and available for dynamic loading

Using Registry Components

import { Index } from "@/__registry__";

// Dynamic component loading
const ChartComponent = Index.charts["bar-chart"].component;

// Use in JSX
<ChartComponent data={chartData} />;

Layout Components

Page Layouts

// src/components/layout/layouts/page-layout.tsx
import { Container } from "@/components/container";
import { Section } from "@/components/section";

interface PageLayoutProps {
  children: React.ReactNode;
  title?: string;
  description?: string;
}

export function PageLayout({ children, title, description }: PageLayoutProps) {
  return (
    <Container>
      <Section>
        {title && <h1>{title}</h1>}
        {description && <p>{description}</p>}
        {children}
      </Section>
    </Container>
  );
}

Section Components

// src/components/section/section.tsx
import { cn } from "@/lib/utils";
import { forwardRef } from "react";

interface SectionProps {
  className?: string;
  children?: React.ReactNode;
  id?: string;
}

const Section = forwardRef<HTMLElement, SectionProps>(
  ({ className, children, id, ...props }, ref) => {
    return (
      <section ref={ref} id={id} className={cn("py-16", className)} {...props}>
        {children}
      </section>
    );
  }
);

Section.displayName = "Section";

export { Section };

Feature Components

Contact Form Components

// src/components/contact/contact-form.tsx
import { useState } from "react";
import { Button } from "@/components/ui/button";
import { Input } from "@/components/ui/input";
import { Textarea } from "@/components/ui/textarea";

export function ContactForm() {
  const [formData, setFormData] = useState({
    name: "",
    email: "",
    message: "",
  });

  const handleSubmit = async (e: React.FormEvent) => {
    e.preventDefault();
    // Handle form submission
  };

  return (
    <form onSubmit={handleSubmit} className="space-y-4">
      <Input
        placeholder="Your Name"
        value={formData.name}
        onChange={(e) => setFormData({ ...formData, name: e.target.value })}
      />
      <Input
        type="email"
        placeholder="Your Email"
        value={formData.email}
        onChange={(e) => setFormData({ ...formData, email: e.target.value })}
      />
      <Textarea
        placeholder="Your Message"
        value={formData.message}
        onChange={(e) => setFormData({ ...formData, message: e.target.value })}
      />
      <Button type="submit">Send Message</Button>
    </form>
  );
}

Chart Components

// src/components/charts/bar-chart.tsx
import { BarChart, Bar, XAxis, YAxis, CartesianGrid, Tooltip, ResponsiveContainer } from "recharts";

interface BarChartProps {
  data: Array<{
    name: string;
    value: number;
  }>;
}

export function BarChart({ data }: BarChartProps) {
  return (
    <ResponsiveContainer width="100%" height={300}>
      <BarChart data={data}>
        <CartesianGrid strokeDasharray="3 3" />
        <XAxis dataKey="name" />
        <YAxis />
        <Tooltip />
        <Bar dataKey="value" fill="#8884d8" />
      </BarChart>
    </ResponsiveContainer>
  );
}

Styling Components

Using Tailwind CSS

// Utility-first approach
<div className="flex items-center justify-between rounded-lg bg-white p-4 shadow-md">
  <h2 className="text-xl font-semibold text-gray-900">Title</h2>
  <Button variant="default-alt" size="sm">
    Action
  </Button>
</div>

Using CSS Variables

// Using design system variables
<div className="bg-background text-foreground border-border rounded-lg border p-4">
  <h2 className="text-primary text-2xl font-bold">Title</h2>
  <p className="text-muted-foreground">Description</p>
</div>

Custom CSS Classes

/* src/app/globals.css */
.custom-component {
  @apply rounded-lg border border-border bg-background p-4;
}

.custom-component:hover {
  @apply shadow-lg transition-shadow duration-200;
}

Component Testing

Unit Testing

// __tests__/components/button.test.tsx
import { render, screen } from "@testing-library/react";
import { Button } from "@/components/ui/button";

describe("Button", () => {
  it("renders with correct text", () => {
    render(<Button>Click me</Button>);
    expect(screen.getByText("Click me")).toBeInTheDocument();
  });

  it("applies variant classes", () => {
    render(<Button variant="destructive">Delete</Button>);
    expect(screen.getByRole("button")).toHaveClass("bg-destructive");
  });
});

Integration Testing

// __tests__/components/contact-form.test.tsx
import { render, screen, fireEvent } from "@testing-library/react";
import { ContactForm } from "@/components/contact/contact-form";

describe("ContactForm", () => {
  it("submits form with correct data", async () => {
    render(<ContactForm />);

    fireEvent.change(screen.getByPlaceholderText("Your Name"), {
      target: { value: "John Doe" },
    });

    fireEvent.click(screen.getByText("Send Message"));

    // Assert form submission
  });
});

Performance Optimization

Lazy Loading

import { lazy, Suspense } from "react";

const HeavyComponent = lazy(() => import("./HeavyComponent"));

function App() {
  return (
    <Suspense fallback={<div>Loading...</div>}>
      <HeavyComponent />
    </Suspense>
  );
}

Memoization

import { memo, useMemo } from "react";

const ExpensiveComponent = memo(({ data }: { data: any[] }) => {
  const processedData = useMemo(() => {
    return data.map((item) => ({
      ...item,
      processed: true,
    }));
  }, [data]);

  return <div>{/* Render processed data */}</div>;
});

Code Splitting

// Dynamic imports for route-based code splitting
const BlogPage = lazy(() => import("@/app/blog/page"));
const DocsPage = lazy(() => import("@/app/docs/page"));

Accessibility

ARIA Attributes

<button aria-label="Close dialog" aria-expanded={isOpen} aria-controls="dialog-content">
  <CloseIcon />
</button>

const handleKeyDown = (e: React.KeyboardEvent) => {
  if (e.key === "Enter" || e.key === " ") {
    e.preventDefault();
    handleClick();
  }
};

<button onKeyDown={handleKeyDown} onClick={handleClick}>
  Action
</button>;

Focus Management

import { useRef, useEffect } from "react";

function Modal({ isOpen, onClose }: { isOpen: boolean; onClose: () => void }) {
  const firstFocusableRef = useRef<HTMLButtonElement>(null);

  useEffect(() => {
    if (isOpen && firstFocusableRef.current) {
      firstFocusableRef.current.focus();
    }
  }, [isOpen]);

  return (
    <div role="dialog" aria-modal="true">
      <button ref={firstFocusableRef} onClick={onClose}>
        Close
      </button>
    </div>
  );
}

Component Documentation

JSDoc Comments

/**
 * A customizable button component with multiple variants and sizes.
 *
 * @param variant - The visual style variant of the button
 * @param size - The size of the button
 * @param children - The content to display inside the button
 * @param className - Additional CSS classes to apply
 */
interface ButtonProps {
  variant?: "default" | "destructive" | "outline" | "secondary" | "ghost" | "link";
  size?: "default" | "sm" | "lg" | "icon";
  children?: React.ReactNode;
  className?: string;
}

Storybook Integration

// Button.stories.tsx
import type { Meta, StoryObj } from "@storybook/react";
import { Button } from "./button";

const meta: Meta<typeof Button> = {
  title: "UI/Button",
  component: Button,
  parameters: {
    layout: "centered",
  },
  tags: ["autodocs"],
};

export default meta;
type Story = StoryObj<typeof meta>;

export const Default: Story = {
  args: {
    children: "Button",
  },
};

export const Destructive: Story = {
  args: {
    variant: "destructive",
    children: "Delete",
  },
};

Troubleshooting

Common Issues

Component not rendering:

Check import paths
Verify component is exported
Check for TypeScript errors

Styling not applying:

Verify Tailwind classes are correct
Check CSS variable definitions
Ensure proper className prop usage

Performance issues:

Use React DevTools Profiler
Check for unnecessary re-renders
Implement proper memoization

Accessibility issues:

Run pnpm a11y:scan or use the a11y-accessibility MCP server in Cursor (test_accessibility)
Check ARIA attributes
Test keyboard navigation

Best Practices

Follow the component hierarchy - UI → Layout → Feature → Content
Use TypeScript interfaces for all component props
Implement proper error boundaries for robust error handling
Write comprehensive tests for critical components
Document components with JSDoc and Storybook
Optimize for performance with lazy loading and memoization
Ensure accessibility with proper ARIA attributes and keyboard support
Follow design system patterns and conventions

For questions about component development, check the other documentation sections or contact the development team.

Content Management Build Deployment

Component Development Guide

Component Development Guide

Component Architecture

Component Structure

Adding New UI Components

Using shadcn/ui (Recommended)

Available shadcn/ui Components

Creating Custom Components

Component Template

Component Best Practices

Example: Custom Card Component

Component Registry System

Registry Structure

Adding Components to Registry

Using Registry Components

Layout Components

Page Layouts

Section Components

Feature Components

Contact Form Components

Chart Components

Styling Components

Using Tailwind CSS

Using CSS Variables

Custom CSS Classes

Component Testing

Unit Testing

Integration Testing

Performance Optimization

Lazy Loading

Memoization

Code Splitting

Accessibility

ARIA Attributes

Keyboard Navigation

Focus Management

Component Documentation

JSDoc Comments

Storybook Integration

Troubleshooting

Common Issues

Best Practices
